Topstar TSED240V/ is a Level 2 dual-ports commercial EV charger with a powerful capacity of up to 80Ax2, user-friendly 7-inch screen design, compliant with ISO 15118-2/3 standards, making it an ideal solution for commercial use. It is CTEP (California's Type Evaluation Program) certified, ensuring metering accuracy and transparency, and has ETL, FCC, ENERGY STAR, CDFA certifications for compliance and excellence.
| ModelNumber | TSED240V/48A2US | TSED240V/80A2US |
| Input Current | Max.48Ax2 | Max.80Ax2 |
| Input Voltage | 208-240V/60Hz | |
| Network Connectivity | Ethernet,Wi-Fi,Bluetooth and 4G with SIM card | |
| Use Management | RFID included | |
| Credit Card Reader | Configurable | |
| Local Load Management | Configurable | |
| OTA Technology | Included | |
| Charging Connectors &Cable | SAE J1772 and Tesla (SAE J3400)Optional | |
| Number ofPort | Dual | |
| Charging Cable | 18FT/25FT | |
| Communication Protocol | OCPP 1.6JSON | |
| ISO 15118 | Included | |
| AC Input Connection | L1+L2+GND+L1+L2 | |
| Max Output,60Hz | 48Ax2/11.5kWx2 | 80Ax2/19.2kWx2 |
| Dimensions(HxWx D) | 19.7"x14.2x6.1 inches | |
| IPProtection | NEMA Type 4 | |
| Tamper Resistant | IK10,LCD&RFID excluded | |
| Cable Management | Optional (7FT Pedestal Only) | |
| Operating Temperature | -22 to 122*F | |
| Humidity | 5%~95%RH,non-condensing | |
| Operating Altitude | ≤(6560FT)2000m | |
| Function Protection | UVP,OVP,OCP,OTP,SPD,RCDGround Fault Protection, Control Pilot Fault Protection | |
| Safety | UL2594UL2231 | |
| FCC compliant | Yes | |
| Energy Star Certified | Yes | |
| Smart Meter | Built-in | |
| LCDDisplay | 7-inch LCD Display | |
| Pedestal Compatibility: | ||
| ModelNumber | Description | |
| EVC2/PEDV5FT | 5FT Pedestal,9.8”x3.9”x60”inches,Max2 chargers, ADA Compliant | |
| EVC2/PED/7FT | ADA Compliant | |
Benefits
1. Sleek and sophisticated design
2. Clear ircons on screen
3. Adjustable power as needed
4. One station, two vehicles
5. Compatible with all EV & PHEV models
Features
1. OTA Remote Firmware Updates
2. Enclosure Rating:NEMA Enclosure Type 4
3. NACS & SAE J1772 Cable Optional
4. 7" LCD Screen
5. ISO15118, Ctep,OCPP1.6J and Ctep Fully Compliance
